Seller's Notes
The Specs
Engine & Drivetrain
Type SOHC 4-Stoke, 4-Valve, Single Cylinder
Displacement 443cc
Bore x Stroke 89 x 71.2 mm
Claimed Horsepower 31.95 hp @ 7500 rpm
Claimed Torque 24.63 ft lbs. @ 6500 rpm
Cooling Liquid
Fuel System Electronic Fuel Injection
Ignition Electric
Transmission CVT Automatic H-L-N-R with Engine Braking
Chassis/Suspension
Final Drive Push Button On-Demand 2WD/4WD with Differential Lock
Brakes (Front/Rear) Linked Hydraulic Dual Disc/Linked Hydraulic Disc
Front Suspension 7.5" Independent Dual A-Arm
Rear Suspension 7.5" Independent Dual A-Arm
Front Tires 24 x 8-12
Rear Tires 24 x 10-12
Shocks 5-Position Oil Dampened Preload Adjustable
Towing Capacity 802 lbs
Winch Mounting Plate
Receiver Hitch 2"
Warranty
Warranty One-Year Limited Factory Warranty
Dimensions/Weight
Length 83"
Width 43"
Height 47.6"
Wheelbase 48.2"
Claimed Dry Weight 609 lbs
Ground Clearance 10.2"
Fuel Capacity 3.75 gal
